| مكان المنشأ: | الصين |
|---|---|
| اسم العلامة التجارية: | CoatTech |
| إصدار الشهادات: | CE |
| رقم الموديل: | الفرن -800 |
| الحد الأدنى لكمية: | 1 |
| الأسعار: | USD2000-USD10000/SET |
| تفاصيل التغليف: | مع فيلم منتظم والكرتون |
| وقت التسليم: | بعد 15 يومًا من الإيداع |
| شروط الدفع: | T/T ، Moneygram ، Western Union ، D/A |
| القدرة على العرض: | 50set/شهر |
| اسم: | فرن | مزود الطاقة: | 380V/50Hz/3PH أو خيار آخر |
|---|---|---|---|
| الباب الرئيسي: | نوع الفتح المباشر | محرك: | العلامة التجارية الصينية أو العلامة التجارية للاستيراد |
| السيطرة على sytem: | تبديل نمط أو التحكم في شاشة اللمس PLC | حائط: | Metal Sheld ، EPS ، صخرة الصخور من PU للخيار |
| لون: | خيار أبيض أو آخر | تطبيق: | تجفيف الطلاء |
| مصادر الطاقة: | Eletric | طلاء: | 10-50um |
| خافت: | قابل للتخصيص | ||
| إبراز: | large heating furnace for automobile parts,high temperature drying room for bus parts,polyurethane curing spray booth,high temperature drying room for bus parts,polyurethane curing spray booth |
||
Large heating furnace, high temperature drying room for automobile and bus parts, polyurethane curing
Specification
| Model No | Internal size H×W×D(mm) | Temperature range | Power | Voltage |
| OVEN-900 | 900×600×500 | RT~200℃ | 7.5KW | Customizable |
| OVEN-600 | 1000×800×600 | RT~200℃ | 9KW | Customizable |
| OVEN-500 | 500×600×500 | RT~300℃ | 6KW | Customizable |
| OVEN-800 | 500×800×500 | RT~500℃ | 13KW | Customizable |
| OVEN-1200 | 1200×800×800 | RT~350℃ | 15KW | Customizable |
| OVEN-1000 | 1500×1000×800 | RT~200℃ | 14KW | Customizable |
| OVEN-1500 | 1500×1200×1200 | RT~200℃ | 17KW | Customizable |
| OVEN-1550 | 1550×1200×850 | RT~200℃ | 15KW | Customizable |
| OVEN-1800 | 1550×1800×1200 | RT~200℃ | 21KW | Customizable |
Upon activation, the burner generates intense fluorescent heat through a thermal energy converter, while a fan draws in and filters external air; this air is heated via energy exchange and directed to the top of the baking chamber for secondary filtration. Once the preset temperature is reached, the burner stops, and the fan shuts down after a 15-minute delay; the system reactivates automatically if the temperature falls below the threshold to maintain consistent heat. The entire process terminates automatically after the set baking duration, completing the paint finishing cycle.
Key Features :
This product dramatically speeds up paint drying and streamlines the post-spray workflow while simultaneously eliminating imperfections to deliver professional, high-quality finishes, making it an ideal solution for both industrial and workshop environments.
FAQ
1,Who are we?
CoatTech Intelligent Equipment(Guangzhou) CO.,LTD is a professional enterprise that produces environmental
protection equipment.
2,How do we ensure quality?
Always conduct final inspection before shipment.
3,What can you buy from us?
The main product is spray booth,coating line,painting line.
4,Why do you want to purchase from us instead of other suppliers?
We have been specializing in the production of environmental protection equipment for many years, and are a manufacturer
of environmental protection equipment that integrates design, research and development, production, and after-sales service.
5,What services can we provide?
Accepted delivery methods: FOB, CFR, CIF, EXW, CIP; Accepted payment currencies: USD, EUR, AUD, RMB;
Accepted payment methods: wire transfer, letter of credit, cash.
6,What is your delivery date?
Normally, we will send you our standard specification goods within 10-15 days after receiving your payment.
This depends on the quantity you order.
7,Can you design the artwork(design) according to our requirements?
Of course we can. All products can be customized according to your own design.
8,Are you a factory or a trading company?
We are a factory with our own design and production, and competitive price advantages.
9,Where is your factory located?
Guangzhou City,Guangdong Province, China.
10. How do I get there?
About half an hour's drive from Guangzhou International Airport. Welcome friends from all over the world to our factory.
